Unico i Series User Manual

1. Standard screwdriver
9. Hammer
16. Hex key, 5mm
2. Phillips head screwdriver
10. Drill
17. Unico P/N: A02131-K01.
Communication Tool Kit for
Troubleshooting and upgrading
firmware (requires Windows PC)
3. Knife or wire stripper
11. Tube cutter
4. Tape measure
12. Tube flaring tool
5. Level
13. Torque wrench (Yellow Jacket
#60650 or equal)
18. Refrigerant Scale
6. Sabre saw or hole saw
19. 5/16” Female x 1/4” Male SAE
Hose Adapter
7. Hacksaw
14. Adjustable Wrench
8. Drill bits 5/16" (8 mm) dia.
15. Reamer (for de-burring)
Indoor Unit Model
Item
Qty
Description
IS12MPA
1
1
Remote Control
2
2
Battery, AAA
3
1
Remote Cradle (for mounting)
4
2
Screws
M3036CL1-A
1
1
Adapter, splitter, 1/2F x 3/8F x 5/8M
2
1
Adapter, reducer, 1/4F x 3/8M with washer
Item
Qty
Description
1
1
Adapter, reducer, 3/8M x 1/2F with washer
and flare cap
2
1*
Adapter, reducer, 1/2M x 3/8F with washer
and flare cap
3
1
Cap, pipe, plastic
4
1
Connector, drain, 32mm dia w/ 18mm hose
barb
* The IS36G110 provides quantity of 2.
2
1
2
4
1 3
