Unico i Series User Manual

IS18G050 Spare Parts List
Item
P/N
Description
Qty
1
-
BOTTOM PANEL ASSY
1
2
-
COMPRESSOR MOUNTING
PLATE
1
3
-
INSULATION, COIL RETURN
BEND
1
4
-
COMPR. VIBRATION
ISOLATOR, RUBBER
3
5
A02105-001
COMPR., IS18G050
1
6
-
COMPRESSOR TERMINAL
GASKET
1
7
-
COMPRESSOR TERMINAL
COVER
1
8
-
COMPR. TERMINAL CVR
NUT AND WSHR
1
9
A02071-G01
COMPRESSOR ASSY (ITEMS
4-8)
1
10
-
COMPR. INSULATION
1
11
-
OUTDOOR COIL ASSY
1
12
-
LIQUID SEPARATOR
1
13
-
TUBE ASSY, COMPR.
DISCHARGE
1
14
-
SERVICE VALVE TUBE
ASSY
1
15
-
REV VALVE TUBE ASSY
1
16
A02086-002
REVERSING VALVE
1
17
A02314-001
REV. VALVE SOLENOID
1
18
-
EXP.VALVE TUBE ASSY
(CIRCUIT 1)
1
19
-
EEV TUBE ASSY, CIRC 2
1
20
A02089-001
EEV, CIRCUIT 1(A), 2(B)
2
21
A02323-002
EEV Coil, CIRC 1(A), 2(B)
2
22
-
DEFROST VALVE TUBE
ASSY
1
23
A02091-001
DEFROST VALVE
1
24
A02092-001
DEFROST. VALVE COIL
1
25
-
SERVICE VALVE, 3/8"
2
26
-
SERVICE VALVE, 1/4"
2
27
-
REDUCER, 1/2M-3/8F
1
28
A02165-G01
MAIN PCB ASSY, W/
HEATSINK
1
IS18G050 Spare Parts List
Item
P/N
Description
Qty
34
A02008-G02
EEV CONTROL BOARD, 2V
1
35
-
EEV PCB CABLES
1
36
A02077-001
REFRIGERANT TEMP.
PROBE ASSY
1
37
A02078-001
OCT SENSOR
1
38
A02079-001
OAT SENSOR
1
39
-
OAT SENSOR MOUNT
1
40
-
PANEL, ELECTRICAL
1
41
-
EMI FILTER, MAIN
1
42
-
COMM FUSE HOLDER ASSY
1
43
A02099-001
11P TERMINAL BLOCK
1
44
-
CABLE CLAMP,
5
45
A02080-001
INDUCTOR, 10A
1
46
-
EMI FILTER, SECONDARY
1
47
-
CRANKCASE HEATER, 20W
1
48
-
PAN HEATER, 75W
1
49
A02197-001
PARTITION PANEL
1
50
-
PARTITION PANEL
INSULATION
1
51
-
FAN MOTOR BRACKET
1
52
-
FAN MOTOR MOUNTING
PLATE
1
53
-
SERVICE VALVE, EMIX
1
54
-
EMIX VALVE SUPPORT
BRACKET
1
55
-
HANDLE
1
56
A02081-001
FAN MOTOR
1
57
A02083-003
FAN BLADE
1
58
-
PROTECTIVE GRILLE
1
59
A02189-001
REAR PANEL
1
60
A02198-001
LEFT SIDE PANEL
1
61
-
FAN GUARD
1
62
A02191-003
TOP / FRONT PANEL
1
63
A02198-002
RIGHT SIDE PANEL
1
64
A02193-001
VALVE COVER PANEL
1
65
-
BACK LWR CVR PNL
1
66
-
EMIX PORT COVER
1
67
-
EMIX BRIDGE TUBE ASSY
1
70
A02082-001
CDT SENSOR
1
