The present Operating Manual (OM) is applicable to automatic battery charger of CH-
105 model (hereinafter referred to as ABC).
The Operating Manual is to be used for study of design, principles of operation and
operating rules of ABC while operating it as per its intended use and during maintenance. The
Operating Manual can also be used for obtaining information on battery chargers for developing
the appropriate sections of operating documentation for the equipment in which ABC can be used
as a component.
1. Purpose
The automatic battery charger CH-105 is to be used on marine and river vessels in dry
service spaces of bridge, superstructures or lower decks and it charges accumulator batteries of
various ship equipment (electronic cartography devices, automatic system, radio communication
devices, etc.), as well as other industrial, transport equipment and communication system
equipment.
2. Delivery Set
1. Battery charger CH-105 1 piece
2. Operation manual 1 piece
3. Technical characteristics
Table 1 List of modifications of ABC CH-105.
Parameter
CH-105
CH-105-24
CH-105-2412A
CH-105-
110VDC
CH-105-
220VDC
Input voltage:
110/220 V AC,
50/60 Hz
24 V DC (19 to 72 V)
110 V DC(
72…114)
220VDC (190-
300)
Maximum output
power:
600 W
500 W
350 W
350 W
500 W
Charging voltage:
9 to 30 V DC
(for charging the batteries with operating voltage 12 V or 24 V)
Charging current:
1–20 А
1–16 А
1–12 A
1–16 A
1–14 A
Type of battery
charger:
Automatic
Standard capacity of
charged batteries:
40–200 A×h
40–160 A×h
40–120 A×h
40–160 A×h
400–140 A×h
AB charging time at
10 hours max. up to 80 %
