User’s Manual
V
CHPATER 4. VGA, FLAT PANEL, DOC, IDE FEATURE ....41
4-1. AGP-BUS VGA FEATURE .................................................................. 41
4-2. LCD FLAT PANEL FEATURE............................................................. 42
4-3. PCI BUS AUDIO ADAPTER FEATURE ............................................. 43
4-4. DISKONCHIP FEATURE..................................................................... 44
4-5. DRIVER UTILITY INSTALLATION GUIDE .................................... 45
CHPATER 5. LAN ADAPTER...................................................47
5-1. FEATURES............................................................................................ 47
5-2. UTP CABLE/RJ-45 JACK DEFINITION............................................. 48
5-3. CONNECTING 100BASE-TX FAST ETHERNET NETWORK ......... 49
5-4. CONNECTING 10BASE-T ETHERNET NETWORK ........................ 49
5-5. 10M BASE/100MBASE INSTALLATION NOTICE ........................... 49
5-6. REMOTE BOOT ROM INSTALLATION GUIDE............................... 50
5-7. LED INDICATORS............................................................................... 51
5-8. SETUP PROGRAM ............................................................................. 51
5-9. LAN DRIVER INSTALLATION PROCEDURE.................................. 54
APPENDIX A: FLASH MEMORY UTILITY .........................55
APPENDIX B: CONNECTOR PIN ASSIGNMENT ...............56
APPENDIX C: LIMITED WARRANTY ..................................64
