User’s Manual
III
Specification
:
This manual covers two different layout model of
Pentium embedded motherboard. The respective board layout outlines are
shown on Chapter 1-4/1-5. Please refer to the following description to make
sure which model you have before using.
MODEL
ENDAT-5701 ENDAT-5901
CPU Pentium 75-550MHz,
INTEL MMX, AMD K5/K6/K6-2/K6-3,
IDT C6, Rise MP6, IBM Cyrix 6x86 CPU
System Chipset VIAChipset
VGA Chipset Built-in, With Share Memory Architecture
LCD Feature (Optional) Optional Support TFT/ DSTN LCD
LAN Chipset Realtek 8139A/B/C 10BaseT/100 BaseT(Boot ROM Optional)
Audio Feature (Optional) via AV Card kit
TV-Out (Optional) via AV Card kit
FLASH Disk Socket for DiskOnChip
System Memory Upto 512MB(PC66/PC100)
IDE Interface PCI IDE Support Ultra DMA33/66
Multi I/O Supports 4 Serial and 1 Parallel Ports
COM1, 3, 4 with +5V/+12V Power
Supports RS422/485 for COM2 (Optional)
External Cache 512KB Burst Cache
IrDA / USB Port Yes(Pin Header)
Expansion Slot Extension for PCI/ISA Bus
AD Selector PCI 1
PCI 2
PCI 3
PCI 4
AD24 LAN (INT.A,B,C,D)
AD23 FREE (INT.B,C,D,A)
AD22 FREE (INT.C,D,A,B)
AD21 FREE (INT.D,A,B,C)
Location of Expansion
Slot
At the 7
th
of Standard AT MB At the 6
th
of Standard AT MB
Keyboard / Mouse Jack Two Mini Din Jack and Pin Header
Pin Header for Keyboard / Mouse / VGA / Multi I/O ports
Power Connector PS/2 and ATX Type
Form Factor WD/LPX (220x220mm) PC/AT (223x220mm)
IV
The ENDAT-5701/5901 All-In-One motherboard
TABLE OF CONTENTS
CHAPTER 1. INTRODUCTION.................................................1
1-1. FEATURES.............................................................................................1
1-2. UNPACKING..........................................................................................3
1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS..............................3
1-4. MOTHERBOARD LAYOUT (ENDAT-5701) .......................................4
1-5. MOTHERBOARD LAYOUT (ENDAT-5901) .......................................5
CHAPTER 2. SETTING UP THE MOTHERBOARD..............7
2-1. JUMPERS AND CONNECTORS (ENDAT-5701) ................................. 7
2-2. JUMPERS AND CONNECTORS (ENDAT-5901) ..............................16
2-3. INSTALLING MEMORY...................................................................... 25
2-4. SHARED VGA MEMORY....................................................................25
2-5. INSTALLING RISER CARD ................................................................ 25
2-6. ASSIGNING IRQs FOR EXPANSION CARDS................................... 26
2-7. ASSIGNING DMA CHANNELS FOR ISA CARDS............................ 27
CHAPTER 3. AWARD BIOS SETUP........................................29
3-1. QUICK SETUP......................................................................................29
3-2. DESCRIPTION OF BIOS SETUP OPTIONS....................................... 30
3-3. BIOS FEATURES SETUP..................................................................... 30
3-4. DETAILS OF CHIPSET FEATURE SETUP......................................... 31
3-5. DETAILS OF POWER MANAGEMENT SETUP................................ 33
3-6. PCI CONFIGURATION SETUP ........................................................... 36
3-7. SYSTEM ENVIRONMENT..................................................................37
3-8. INTEGRATED PERIPHERALS ........................................................... 38
