29
Pos.
Name
No. of pieces
Number
45M/45MR
4002.13.00.0
55M/55MR
5002.13.00.0
1
Protective sheet metal
1
4002.00.50.0
5002.00.50.0
2
Upper protection
1
4006.01.45.0
5006.01.45.0
3
Upper protection
1
4006.01.46.0
5006.01.46.0
4
PTO protection kpl.
1
5002.00.60.0
5002.00.60.0
5
Drum cover kpl.
1
5002.11.00.0
5002.11.00.0
6
Support foot
2
5006.00.10.0
5006.00.10.0
7
Hub
2
5006.00.15.0
5006.00.15.0
8
Bolt
2
5006.00.16.0
5006.00.16.0
9
Foot spring
2
5006.00.18.0
5006.00.18.0
10
Screen var.
1
5008.88.00.0
5008.88.00.0
11
Bolt, lower var.
2
502.00.20.0
502.00.20.0
12
Upper tractor bolt Zn
1
502.00.15.0
502.00.15.0
13
Screw M8x16 Zn
3
1000050
1000050
14
Screw M10x70 Zn
2
1010831
1010831
15
Screw M8x20 Zn
8
1000051
1000051
16
Washer M8 Zn
19
1003471
1003471
17
Nut M10 Zn
4
1003461
1003461
18
Nut M8 Zn
8
1003460
1003460
19
Screw M10x25 Zn
2
1000061
1000061
20
Spring latch 6x40
2
1000208
1000208
21
Spring latch 6x30
2
1000214
1000214
22
Cotter pin 5x50
2
1003497
1003497
23
Tube fuse 8x42 mm + chain
2
1004566
1004566
24
Spring latch 10mm + chain 2.2 mm
1
1004565
1004565
25
Grease fitting M8x1
1
1000234
1000234
26
Grommet, large Ø 70
1
1000736
1000736
