The document provided is a Quick User Guide for the N407-TC Koolzone Mobile Spot Cooler, manufactured by Nakatomi Co., Ltd. and exclusively distributed by Uninex International. This guide outlines the device's parts, installation procedures for its ducts, important operational considerations, and how to adjust its direction and manage drainage.

Function Description

The Koolzone Mobile Spot Cooler N407-TC is a portable air conditioning unit designed to provide targeted cooling. It features both a cold air duct for cooling and a heat-removal duct to expel warm air, making it effective in reducing ambient temperatures in specific areas. The unit is equipped with a swing function to distribute cooled air over a wider area, and it includes a drain tank for condensate management, with an option for direct drainage.

Important Technical Specifications

Model: N407-TC
Optimum Operating Temperature Range: 64°F to 104°F (17.8°C to 40°C).
Temperature Reduction: Proper usage of the unit, specifically at the cooling duct, can reduce the ambient temperature by 10°F to 15°F (5.6°C to 8.3°C).
Cooling Outlet Direction: Must be positioned above 30 cm from any obstruction.
Air Outlet Direction: Must be positioned above 30 cm from any obstruction.
Heating Outlet Direction: Must be positioned above 80 cm from any obstruction.
Drain Tank Capacity: 5 liters.
Drain Mouth Diameter: Φ 16 mm for direct drain option.

Usage Features

Parts of the Machine: The Koolzone Mobile Spot Cooler comprises several key components:

Operation Spot: The control panel for operating the unit.
Revolving Switch: Controls the unit's power and possibly fan speed (Low/High).
Swing Switch: Activates the swing function for wider air distribution (ON/OFF).
Duct Cap: Covers the duct openings when not in use or for specific configurations.
Cold Air Duct: Directs the cooled air to the desired area.
Duct Elbow: Connects the ducts to the main unit.
Heat-Removal Duct: Expels warm air generated by the cooling process.
Heat-Removal Mouth: The opening through which the heat-removal duct connects.
Particle Filter: Filters airborne particles from the intake air.
Drain Hose: Used for direct drainage of condensate.
Drain Tank (5L): Collects condensate water.
Caster: Wheels for easy mobility of the unit.

Duct Installation:

Installing the Duct Elbow: The elbow fits into the upper part of the main body. It should be pressed in until it clicks securely into place.
Installing the Cold Air Duct: The recess on the elbow aligns with the convex part of the cold air duct. Once aligned, turn the duct counter-clockwise until it stops, ensuring a secure fit.
Installing the Heat-Removal Duct: When inserting the heat-removal duct, it's crucial to note the recess on the heat-removal mouth for proper alignment and insertion. Care should be taken not to bump the swing installment during this process.

Operation and Direction Adjustment:

Power Control: The "Revolving Switch" likely controls the power (ON/OFF) and fan speed (Low/High).
Swing Function: The "Swing Switch" activates or deactivates the swing mechanism, allowing the cold air duct to rotate up to 200 degrees to cover a broader area.
Direction Adjustment: The cold air duct can be manually adjusted to direct airflow to a specific spot.

Important Distance Considerations: To ensure optimal performance and safety, specific clearance distances must be maintained around the unit's outlets:

Cooling Outlet: Maintain a clear space of at least 30 cm above the outlet.
Air Outlet: Maintain a clear space of at least 30 cm above the outlet.
Heating Outlet: Maintain a clear space of at least 80 cm above the outlet.

Drainage Options: The unit offers two methods for managing condensate water:

Drain Tank: Condensate collects in a 5-liter internal drain tank. The "Red Water Line" likely indicates the maximum fill level. The tank can be extracted for manual emptying.
Direct Drain: For continuous operation or to avoid frequent emptying, a drain hose can be connected to the "Draining Water Mouth" at the base hole. The "Drain Mouth" has a diameter of Φ 16 mm. This allows water to be continuously drained away from the unit.

Maintenance Features

Particle Filter: The presence of a particle filter suggests that it will require regular cleaning or replacement to maintain air quality and unit efficiency. While the guide doesn't detail the cleaning process, it's a standard maintenance item for such devices.
Drain Tank Management: Regular emptying of the 5-liter drain tank is necessary when using this drainage method. The "Red Water Line" serves as a visual indicator for when the tank needs attention.
Duct Cleaning: Although not explicitly stated, periodic cleaning of the cold air and heat-removal ducts would be advisable to prevent dust buildup and maintain airflow efficiency.

The guide emphasizes the importance of reading the instructions before use and keeping them for future reference, highlighting the need for proper installation and operation to achieve the stated temperature reduction benefits. For further assistance, purchase, or rental inquiries, Uninex International can be contacted via phone or their website.
