Smart-i 사용자 가이드 11
㈜유니온커뮤니티 / 서울시 송파구 방이동 44-3 현대토픽스 빌딩 3층 (138-050)
Tel : 02-6488-3000 , Fax : 02-6488-3099, E-Mail :sales@unioncomm.co.kr
http://www.unioncomm.co.kr
2.3. Specifications
Item Spec
Description
CPU 32bit RISC 72MHz
ST Micro
LED 3 LED (Red, White, Blue),
Flash Internal 256k Byte
Nor Flash
Buzzer Sound Possible to control volume
Card Module
125KHz RF
13.56MHz Smart (1 Sam Card Socket Support)
125KHz HID Card
Authentication
Method
Card
I/O
4 Dip Switch
(485 ID Setting : 3pole, Changing 485<->Wiegand
In/Out
Lock Control
- If POE is supported, separate lock Controller is used
- If POE is supported, EM, Strike, Motor Lock are
possible
to use
RS-485 1 Port
Interworking with 485
Controller
Wiegand-Out 1 Port
Display Wiegand signal
output or success/fail
RS-232 3 Port
Debug
Power 12 VDC
