UNIPRODO UNI COOLER 08 User Manual

98
17.10.2019
The product satises the relevant safety
standards.
Read instructions before use.
The product must be recycled.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation (general
warning sign).
ATTENTION! Electric shock warning!
ATTENTION! Rotating parts, entanglement
hazard!
TECHNICAL DATA
Parameter description Parameter value
Product name Evaporative Air Cooler
Model UNI_
COOLER_05
UNI_
COOLER_06
Rated voltage [V~] /
Frequency [Hz]
230/50
Rated power [W] 100 150
Current [A] 3
Protection class I
Protection rating IP IPX0
Blow rates [rpm] 1400/1200/900
Maximum air ow
[m
3
/h]
1500-2000 2000-3000
Dimen-
sions
[mm]
Ice holder
280x160x60 320x190x60
Air outlet,
front
330x340 360x360
Air inlet,
rear
500x280 500x330
Air inlet,
side
280x150
Rear lter
310x540x50 540x335x60
Side lter
160x390x45
Tank capacity [l]
25 40
Water consumption
[l/h]
3-4
Dimensions [mm]
440x350x800 490x380x890
Weight [kg]
12 15
Remote control
Yes No
Maximum fan ow
rate F [m
3
/min]
44.4 61.1
Fan power input P [W]
96.5 125.2
Service value
SV [(m
3
/min)/W]
0.46 0.49
Standby power
consumption PSB [W]
0.25 0
Fan sound power level
LWA [dB(A)]
66.5 67
Maximum air velocity
c [m/s]
3.5 3.4
Measurement
standard for service
value
IEC 60879: 1986 (corr.1992)
Product name Evaporative Air Cooler
Model UNI_
COOLER_07
UNI_
COOLER_08
Rated voltage [V~] /
Frequency [Hz]
230/50
Rated power [W] 150 230
Current [A] 3
Protection class I
Protection rating IP IPX0
Blow rates [rpm] 1400/
1200/900
1300/
1100x900
Maximum air ow
[m
3
/h]
2500-3500 5000-6000
Dimen-
sions
[mm]
Ice holder
325x185x60 490x270x110
Air outlet,
front
360x360 480x480
Air inlet,
rear
50x330 480x490
Air inlet,
side
280x150 480x220
Rear lter
540x335x60 540x470x80
Side lter
160x390x45 545x230x45
Tank capacity [l]
40 60
Water consumption
[l/h]
3-4
Dimensions [mm]
480x380x890 630x410x1140
Weight [kg]
12 22
Remote control
Yes
Maximum fan ow
rate F [m
3
/min]
61.1 87.8
Fan power input P [W]
125.2 205.8
Service value
SV [(m
3
/min)/W]
0.49 0.43
Standby power
consumption PSB [W]
0.25 0.27
Fan sound power level
LWA [dB(A)]
67 66.3
Maximum air velocity
c [m/s]
3.4 3.33
Measurement
standard for service
value
IEC 60879: 1986 (corr. 1992)
2.1. ELECTRICAL SAFETY
a) The plug must t the socket. Do not modify the
plug in any way. Using original plugs and matching
sockets reduces the risk of electric shock.
The terms „device“ or „product“ are used in the warnings
and instructions to refer to <device name>. Do not use
in very humid environments or in the direct vicinity of
water tanks. Prevent the device from getting wet. Risk
of electric shock! Do not cover air inlets / outlets! Do not
put your hands or other items inside the device while
it is in use!
b) Avoid touching earthed elements such as pipes,
heaters, boilers and refrigerators. There is an
increased risk of electric shock if the earthed
device is exposed to rain, comes into direct
contact with a wet surface or is operating in
a damp environment. Water getting into the
device increases the risk of damage to the device
and of electric shock.
c) Do not touch the device with wet or damp hands.
d) Use the cable only for its designated use. Never
use it to carry the device or to pull the plug out of
a socket. Keep the cable away from heat sources,
oil, sharp edges or moving parts. Damaged or
tangled cables increase the risk of electric shock.
e) If using the device in a damp environment cannot
be avoided, a residual current device (RCD) should
be applied. The use of an RCD reduces the risk of
electric shock.
f) Do not use the device if the power cord is damaged
or shows obvious signs of wear. A damaged power
cord should be replaced by a qualied electrician
or the manufacturer‘s service centre.
g) To avoid electric shock, do not immerse the cord,
plug or device in water or other liquids. Do not
use the device on wet surfaces.
2.2. SAFETY IN THE WORKPLACE
a) If there are any doubts as to the correct operation
of the device, contact the manufacturer‘s support
service.
b) Only the manufacturer‘s service point may
repair the device. Do not attempt any repairs
independently!
c) In case of re, use a powder or carbon dioxide
(CO2) re extinguisher (one intended for use on
live electrical devices) to put it out.
d) Use the device in a well-ventilated space.
e) Regularly inspect the condition of the safety
labels. If the labels are illegible, they must be
replaced.
f) Please keep this manual available for future
reference. If this device is passed on to a third
party, the manual must be passed on with it.
g) Keep packaging elements and small assembly
parts in a place not available to children.
h) Keep the device away from children and animals.
2.3. PERSONAL SAFETY
a) Do not use the device when tired, ill or under
the inuence of alcohol, narcotics or medication
which can signicantly impair the ability to
operate the device.
b) The device is not designed to be handled by
persons (including children) with limited mental
and sensory functions or persons lacking relevant
experience and/or knowledge unless they are
supervised by a person responsible for their
safety or they have received instruction on how to
operate the device.
c) When working with the device, use common sense
and stay alert. Temporary loss of concentration
while using the device may lead to serious
injuries.
d) To prevent the device from accidentally switching
on, make sure the switch is on the OFF position
before connecting to a power source.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this
user manual and regularly perform maintenance tasks.
The technical data and specifications in this user manual
are up to date. The manufacturer reserves the right to
make changes associated with quality improvement.
The device is designed to reduce noise emission risks to
a minimum, taking into account technological progress
and noise reduction opportunities.
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
LEGEND
Protection class I device with a protective
earth connection.
Only use indoors.
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details may
differ from the actual product.
The original operation manual is written in German.
Other language versions are translations from the
German.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in serious injury or even
death.
USER MANUAL
ENEN
