UNIQUE UGP 13
28
Pop off the three plugs that are located on the left side of the fridge cabinet from where
the middle hinge will be transferred to and plug them into the right side where you just
removed the middle hinge.
Remove the 3 bolts that hold the bottom hinge in place using a ratchet tool with a 10
mm socket or a Phillips screwdriver.
Now, loosely mount the bottom hinge to the left side of the cabinet with the three bolts
and move the hinge pin from the right side of bracket to the left side of bracket as shown.
Ensure all washers and caps are moved over with the pin.
emove bolts
Move hinge pin from right
side of bracket to left
