UNIQUE UGP 13
27
Lift off the freezer door from the middle hinge and place it on a padded surface to
prevent scratching and remove the plug from the right top side of the freezer door and
move it to the left.
Remove the hinge cover from the upper left side, one screw, and transfer over to the
right side.
Pop off the caps covering screws that are holding middle hinge in place and retain,
Unscrew the middle hinge using a Phillips screwdriver, retain for use later.
Once hinge has been removed, lift off the fridge door from the bottom hinge pin and
place on padded surface to prevent scratching.
Remove caps
