15
TECHNICAL SPECIFICATIONS
MODEL UGP-80L1 W
GROSS CAPACITY
80 L / 2.8 cubic feet
ZONE
Dual
RUN TEMPERATURE
-22˚C/-7.6˚F to +20˚C/68˚F (in ambient temperature
between +1˚C/34˚F to +43˚C/109˚F)
POWER CONSUMPTION
33 W (power consumption varies based on temp. setting)
AVERAGE RUN CURRENT
2.7 amps on 12V DC
TOTAL WATT HR DRAW
378 Wh/24 hrs (lrg. side set to +5˚C/Sm. side set to -13˚C)
TOTAL AMP HR DRAW
9.3 Ah/24 hrs (lrg. side set to +5˚C/Sm. side set to -13˚C)
REFRIGERANT
R134a / 85g
INSULATION MATERIAL
C5H10/C-Pentane
INSULATION THICKNESS
Wall: 55mm / Lid: 50mm
WEIGHT (kg, approx.)
29 kg / 63.9 lbs
EXTERNAL DIMENSION
(WxDxH)
20.9” x 31.5” x 18.5”
INTERNAL DIMENSION
large chamber - 1 (LxWxD)
13.9” x 8.4” x 15.4”
INTERNAL DIMENSION
large chamber - 2 (LxWxD)
13.9” x 8,4” x 6.6”
INTERNAL DIMENSION
small chamber (LxWxD)
13.9” x 8.3” x 15.4”
