FUNCTION DESCRIPTION RANGE
Weld Programs
Each program is a complete RWMA Schedule including
Forge Delay, Pulsation, and Special Sequences for welding
galvanized steel and other coated metals.
800 Customer Set
100 RWMA Preset
Display Bright blue vacuum uorescent, full alpha/numeric. 80 Characters
Welds Counter Keeps track of welds made. 1-65,500
Parts Counter Keeps track of nished parts made. 1-65,500
Batch Counter Stops welder when batch is completed. 1-999
Master Setup Program Quick setup of system programs using Wizard Tutorial. -
AVC
Automatic line voltage compensation.
Maintains welder output with variations of incoming line voltage.
1% Max. Variation
with +/-10% Line Voltage Change
Keyboard Lock Prevents unauthorized changes in welding schedules or setup values. 3 Security Levels
Heat Stepper
Computerized curve for welding galvanized steel.
Just enter total welds and last heat % increase.
999 Welds
Tip Force Calculator
Displays required pressure regulator setting
needed to produce requested electrode force.
0-99 psi
Line Service
Single selector wire to match line voltage.
Keypad entry for line frequency.
115V - 575V
50/60Hz
Dual Program Assigns any weld schedule to one of two initiation inputs. -
Initiation Modes Single level, dual level, anti-tiedown; holding or momentary. -
Low Water Flow Input from external water ow switch. -
Light Curtain Input for light curtain, factory programmed. -
So Touch Function
Exclusive UNITROL operator pinch point protection safety system.
Requires So Touch hardware kit.
-
SD Slot Copy programs, install programs, modify operating system. -
Anti-tiedown Initiation Requires closing of two hand switches within 1 second to start weld. -
Pressure Transducer*
Starts weld when selected electrode force has been reached.
Locks electrodes on part at end of weld if force exceeds
customer-set limit to prevent cold welds.
0-99 psi
Current Monitor*
Compares RMS current to program high/low range.
Locks electrodes closed if out of range.
10KA - 200KA
Constant Current*
Accurately provides program-selected secondary current.
Current values are directly entered in amps.
0-200KA
+/-1% Range F.S.
Communication Port* Export of weld results; upload / download schedules. RS-232 or RS-485
Electronic
Pressure Regulator**
Automatically sets pressure regulator to provide
program-selected electrode force.
0-99 psi
* included with SOLUTIONiQC controls ** optional feature
Specication Chart
UNITROL
UNITROL ELECTRONICS, INC.
Northbrook, Illinois
847-480-0115 / info@unitrol-electronics.com
www.unitrol-electronics.com
