Pirate’s Hook Manual
17
No. Part No. Draw No. Name Qty
1 X109-201-000 202.4.11.22.001 PC fixed board 1
2 X109-601-000 206.4.11.22.001 PC foam 1
3 X109-202-000 202.4.11.22.003 Bottom L&R T-molding 2
4 X109-203-000 202.4.11.22.004 Front T-molding 1
5 X109-403-000 202.4.11.22.005 Coin door 2
6 X109-204-000 202.4.11.22.006 Ticket box 2
7 X109-205-000 202.4.11.22.007
Control panel either side
plastic pressure plate
2
8 X109-602-000 206.4.11.22.004
Control panel either side
plastic
2
9 X109-206-000 202.4.11.22.009 Speaker base 2
10 X109-207-000 202.4.11.22.010 Monitor base 1
11 X109-208-000 202.4.11.22.011 Monitor base back board 1
12 X109-209-000 202.4.11.22.012 Monitor front cover board 1
13 X109-210-000 202.4.11.22.013 Glass pressure bar 2
14 X109-603-000 204.4.11.22.001 Monitor glass 1
15 X109-604-000 206.4.11.22.003 Monitor long foam 2
16 X109-605-000 206.4.11.22.002 Monitor short foam 2
17 X109-211-000 202.4.11.22.017 Monitor L&R fixed board 2
18 X109-502-000 203.4.11.22.002 PC fix board 1
19 X109-212-000 202.4.11.22.019 Power pressure plate 1
20 X109-213-000 202.4.11.22.020 Back T-molding 1
21 X109-214-000 202.4.11.22.021 Button fixed board 2
22 X109-701-000 205.4.11.22.002 Speaker plastic 2
23 X109-404-000 2.60.00005000 Wire box support base 1
24 X109-405-000 2.60.00012000 Shockproof screw A 4
25 X109-406-000 2.53.00171001 Lock 8
26 X109-501-000 2.99.4.11.22.001 Wooden part 1
27 X109-401-000 2.60.00008000 2.5” leveler 4
28 X109-402-000 2.60.00010000 2.5” caster 4
