Universal Chilling Systems, LLC.
Manual Model 10 Air Cooled Chiller
If the sensor of T.out or T.in shows no temp, the show will be °C , ERR shows…ºC
a.
Welcome show
WELCOME TO OUR
CONTROLLER
b.
Model show (Water cooled chiller), mode (cool only, Heat pump, E heating), run mode
(cool,
heat, fan, water, defrost) and start type (manual, timing).
c. Face show: show main temp (T.in, T.out), set temp and running status (run, time delay,
stop).
The reverse color shows the control temp for energy adjustment (T.in as control temp as fig below).
T.IN means temperature of returning water or air; T.OUT means temperature of out water or air
3. User’s Inquiry Operation
Press ENQIRE, shows as below:
TROUBLE LIST
TROUBLE HIS.
This system includes inquiring content as below:
TROUBLE LIST
TROUBLE HIS.
RUN TIME CHECK
CLOCK CHECK
Select by or , enter each page by OK, by RETURN come back to main face.
