Universal UCS Series - Technical Specifications

Universal Chilling Systems, LLC.
4
Manual Model 10 Air Cooled Chiller
1.2 Specifications
MODEL
UCS-10A
Cooling Condition
Chilled Water Inlet Temp.
12º C
Chilled Water Outlet Temp.
7º C
Ambient Temp.
35º C
Nominal Cooling Capacity
KW
30
x 10³kcal/Hr
25.8
Power Supply
3P-440V-60Hz
Compressor
Type/QTY
Fully Closed Scroll/1 piece
Cooling Input Power(KW)
10.40
Cooling Operation Current(A)
15.10
Evaporator
Chilled Water Flow(m³/h)
5.16
Interface Size
DN40
Condenser Fan
Quantity
2
Power/KW
0.64
Operation Current(A)
0.99
Safety Protection Device
High &low voltage protection, current overload protection,
antifreezing protection, electronical delay protection
Water Pump
Power (KW)
1.1
Current (A)
2.42
Head(M)
30
Water Tank
Material
304SS
Volume(L)
140
Overall Size
Length (mm)
1810
Width (mm)
975
Height (mm)
1730
Overall Unit
Weight /KG
435
Power/KW
12.78
Current(A)
19.5
Refrigerant Type
R407C
Notice:
1) Normal conditions: Chilled water inlet temperature 12º C, outlet temperature 7ºC, ambient temperature
35ºC
2) Standard power supply: 3P-440V-60Hz, proposed three-phase four-system, allowing voltage fluctuation
-25~10%, frequency fluctuation ± 2%.
3) Host for the actual lift is pump lift host internal head loss minus. (1mH20=9.8kPa)
