5.9 Hard disk drive test error
Symptom: Either an error message is shown, or the drive motor spins non-stop,
while reading data from or writing data to Hard disk
Hard disk test error
Replace the faulty parts
Re-boot ok?
Replace motherboard
Board level troubleshooting
Check HDD
connector, PCI-
IDE controller
for cold solder?
Re
-
solder
Yes
No
Yes
No
One of the following parts on the M/B may be detective, replace the
parts one at a time and test after each replacement.1. HDD
connector
2. PCI
-
IDE controller
Try another working HDD
Check BIOS
HDD Setup OK?
Correct it
Yes
No
