Chapter 5 Troubleshooting Guidelines
340S2 71 Rev : B
5.17 PCMCIA CardBus failure
Symptom : when insert PCMCIA card to PCMCIA slot, but system can’t
detect.
Re-soldering
PCMCIA card failure
Insert PCMCIA card completely again,
make sure good connection.
Check drive &
controller install OK?
Correct it
Board-level Trouble shooting
Check PCMCIA slot
mounting in M/B is cold
soldering
Check O2Micro OZ
6812 Chipset for cold
solderin
g?
Re-solder
Replace O2Micro OZ6812
chipset
No
Yes
Yes
No
Yes
No
