4
HE.15874 - Mini² - 01/2015
made by
Mini
2
GB
Instruction Manual
authorised
copy
A manual retraction allows the user to return the piston into the starting position in case of an incorrect crimp.
The pressing head can be smoothly turned by 350° around the longitudinal axis in order to gain better access to tight
corners and other diffi cult working areas.
The unit is equipped with a microprocessor (page I, pic. 1.3) which shuts off the motor automatically after the com-
pression is completed, indicates service intervals, checks battery capacity and does a trouble check e.g. informing
the user through optical warning signals about the kind of error.
Power saving function through motor switch-off.
The ergonomically formed compact housing is made of 2 components. The grip area is rubber coated and is therefore
non-slip. Together with the improved center of gravity the tool allows fatigue-free working.
All tool functions can be controlled by one trigger. This results in an easy handling and a better grip compared to a
two button operation.
Li-Ion batteries do neither have a memory effect nor self discharge. Even after long periods of non operation the tool
is always ready to operate. In addition we see a lower power weight ratio with 50% more capacity and shorter char-
ging cycles compared to NiMH batteries.
The oil used in our tool is highly biologically degradeable and not hazardous to water and has been rewarded „
The
Blue Angel
“. The oil is suitable for low temperatures and has excellent lubrication characteristics.
At the end of a job a print-out via a USB adapter can be generated documenting the proper function of the tool.
3.3 Description of the tool indication
See page VI - X, tab. 1
