3.2.3 TIME (SEARCH BY DATE AND TIME)
This option is used to define recording search by date and time.
Use “◄►” to point the cursor to the day/month/year of the period to be set.
Press “▲▼” to select day/month/year and hours/minutes.
Specific messages will appear if times overlap.
3.2.4 CARD NO
For future developments.
3.2.5 SEARCH
Select “SEARCH” to start searching according to the set parameters.
The hit list will appear in the box underneath. Seven recordings will be shown on each page. To scroll the pages, position the
“Active Frame” on “Page n°.” and press “▲▼” or directly enter the page number.
Use “▲▼” to select the recording.
A specific message will appear if the device finds no recordings which satisfy the set search criteria.
3.3 PLAYING A RECORDING
After setting the search parameters (event type, date and time) and having start the search by pressing “SEARCH”, select the file
to be played from the list box and press “ENTER” to start playback.
The monitor will appear as below if two video channels are played:
Figure 35: playback of 1 video channel
The control interface shown below appears in the lower part of the screen:
; 50% 1x 00:25:30/00:50:15 Press EDIT to start copying
Total playback time
Elapsed time
Playback speed
Playback advancement percentage
Playback with audio (with 1093/041 and 1093/066 only)
Press “ENTER” to stop playback.
Press “ENTER” to resume playback.
Press “▲” repeatedly to increase the playback speed with respect to normal speed (1x). Several speeds are available.
Press “▼” repeatedly to decrease the playback speed with respect to normal speed (1x). Several speeds are available. Select
“Single” to play one frame at a time and press “ENTER”.
Press “PLAY” to mute the audio (function available only on devices provided with audio function: ref.1093/064 and ref. 1093/066).
Press “MENU” to show or hide the command interface bar.
Press “ESC” to quit playback mode.
3.3.1 PLAY
Select “Play” to start playback without interruption of recordings according to the set search parameters. Playback will stop when
the end of the last recording on the last page of the list box is reached.
DS1093-013 47
