DS1093-106A 45
2.2 BESCHREIBUNG DER TEILE -TYP 1093/184M11 – TYP 1093/184M12
1 Objektiv 5 Mikrofon 9 Port Ethernet 13 Reset
2 Status LED 6 IR LED 10 Versorgung 14 In/Out
3 Scharfeinstellring 7 Antenne 11 Befestigung Halter 15 WPS-Taste
4 Lautsprecher 8 PIR Bewegungssensor 12 Steckplatz Micro-SD 16 Lichttaster
2.3 BESCHREIBUNG DER TEILE - TYP1093/184M14
1 Objektiv 5 Stopper Gehäuse 9 Versorgung
2 Lichtssensor 6 Mikrofoneingang (rosa) 10 Ethernet Verbindung
3 IR LED 7 Audio Ausgang (grün) 11 Klemmleiste
4 durchsichtige Kuppel 8 Video Ausgang 12 Steckplatz Micro-SD
13
3
5
4
6
1
7
8
16
2
10
11
12
15
9
14
12
5
1
2
3
4
6
7
8
9
10
11
