Urrea UP779 - Technical Data

7
ENGLISH•User’s manual
LUBRICATION
The parts shown in the assembly for proper
operation of your air tools are identified as
follows:
1. Air filter.
2. Regulator.
3. Lubricator.
4. Emergency shut-off valve.
5. Hose diameter.
6. Thread size.
7. Coupling.
8. Safety Air Fuse.
9. Oil.
10. Grease (During assembly).
COLLET CAPACITY
AIR FLOW
RECOMMENDED AIR PRESSURE
AIR INLET
HOSE INTERNAL DIAMETER
NO LOAD SPEED
MAXIMUM TORQUE
WEIGHT
TECHNICAL DATA
1/4” (6,35 mm)
4 CFM
90 PSI
1/4” NPT
3/8” NPT
25 000 r/min
45-115 in-lb (5-13 Nm)
1,1 kg (2,5 lb)
1/4” (6,35 mm)
4 CFM
90 PSI
1/4” NPT
3/8” NPT
1 800 r/min
115 in-lb (13 Nm)
1,1 kg (2,5 lb)
UP780UP779
24h
48h
90 psi
