4.1
4.3
4.4
4.2
Loosen the screw for
fixing the fender on
the fork.
Align the fender holding hole with
the fork's screw hole.
Adjust the height of the fender
and then use a 3mm hex
wrench to tighten the screw.
Use a 3mm hex wrench to remove
the screw from the fork's fender
stay and then install the stay and
tighten it. Make sure the distance
between the left and right stays
and the tire is consistent.
4. Install Front Fender
1
3mm
Hex Wrench
2
3mm
Hex Wrench
14
3mm
Hex Wrench
To Next Page
