6.1
Use a 6mm Hex Wrench to install the left (L) and right (R) pedals.
Pay attention to the tightening direction of the Hex Wrench and
follow the arrow in the diagram.
6.2
Use a 5mm hex wrench to
remove the locking screw
on top of the kickstand.
6.3
Align the screw holes of the
kickstand with the holes on
the frame and then use a 5mm
hex wrench to tighten them.
6. Install Pedals and Kickstand
5mm
Hex Wrench
5mm
Hex Wrench
16
R
L
6mm
Hex Wrench
