Remove the seat post cover from the
tool box, and slide the cover onto the
seat post from the bottom.
Insert the clamp and adjust the height
of the seat post so that the saddle and
the top tube are aligned and centered.
Use a 5mm hex wrench to
tighten the clamp with a
torque of 8-10N·m.
Snap the cover onto the clamp position.
7.1
Insert the seat post into the
frame's seat tube.
7.2
7.3
7.5
7.4
7. Install Seat Post
5mm
Hex Wrench
8-10 N·m
1
2
17
