Urtopia CHORD - Install Battery

Remove the battery and accompanying key from the battery box. Align the
keyhole end with the seat tube direction and the other end with the head tube
direction when installing.
First align and install the head tube direction and then insert the other end into
the battery base.
Install
Remove
8.1
8.2
8. Install Battery
The battery has two locks. Use the key to loosen and remove the first lock, then
push the second lock slider back to remove the battery.
When removing the battery, be sure to hold the battery firmly to avoid dropping it.
1
2
A
1
2
3
4
Notice： 1. Before first use, please activate the battery by connecting it to a power source with the
charger.After activation, it can be used normally.
2. It is recommended to remove the key while riding and store it properly to avoid loss.
