USB 3451 / 3461 - 3471 - 3481
Car Power Amplifier
ELECTRICAL CONNECTION
13 +12V Anode of power connection terminals. Connect to the anode of car battery.
REM Terminal to be connect with Remote cable, which comes from the source and which
controls the amplifier switching on. Applied voltage must be between 7 and 15VDC.
GND Ground terminal. Connect to the car underpan . Keep the length of the ground cable
to a minimum.
SPECIFICATIONS
Model USB 3451 USB 3461 USB 3471 USB 3471
RMS Power @ 13.8 VDC
4 Ohm Stereo 4x80 Watt 4x120 Watt 2x150 Watt 2x200 Watt
2 Ohm Stereo 4x100 Watt 4x150 Watt 2x180 Watt 2x250 Watt
4 Ohm Bridged 2x160 Watt 2x250 Watt 300 Watt 400 Watt
Impedance 2 Ohm
THD Distorsion 0.08%
IMD Distorsion 0.08%
Frequency response 20 Hz~20 KHz
Input Sensitivity 200 mV~6V
Input Impedance 15K
Signal-to-noise Ratio 90 dB
Channel seperation 50 dB
Remote Bass Control 0dB~+12 dB
Crossover Network
Low Pass Filter 40 Hz~250 Hz
Bass Boost 0 dB~+12 dB
High Pass Filter 80 Hz~500 Hz
Fuse Rating 4x20 A 4x20 A 2x20 A 2x20 A
Size (HxWxD) 65x258x468 mm 65x258x528 mm 65x258x398 mm 65x258x468
© US Blaster Europe BV
