USA SPECS BT45-ACU User Manual

13
Transferring an active call from Hands-free to
Handset
From radio: Press TUNE UP
button
From Steering wheel: Press
CH+ button
Press the same button again
to transfer the call back to the
Bluetooth Hands-Free mode.
Aux 3.5 mm Audio Input
1. You'll need a 3.5mm to headphone jack cable (not included
in this package)
2. Make sure DIP switch #1 is set to ON
Go to XM1 then press Preset 6
to access the audio device
connected to the AUX port.
Note: Remember to manually adjust the volume of your audio
device to MAX after it's been connected.
Maximum charging ouput: 2.1 amps at 5 volt
(charging cable noto provided)
AUX Input
USB Charging Port

USA SPECS BT45-ACU Specifications

General

Product Type	Bluetooth Adapter
Bluetooth Version	Bluetooth 4.0
Wireless Range	Up to 30 feet
Audio Streaming	Yes
Hands-Free Calling	Yes
Features	hands-free calling
