Ussc 19
REPAIR PARTS
1
2
4
3
5
8
7
6
9
10
11
12
13
14 15
KEY DESCRIPTION PART NO. QTY
1 Flue Collar 25269B 1
2 Feed Door 25266 1
3 Door Handle 25097B 1
4 Door Handle Pin 83506 1
5 Hinge Pin 83443 2
6 Magnolia Glass 891096 1
7 Bottom Glass Retainer 25270 1
8 Top Glass Retainer 25178 1
9 Heat Shield Deflector 25265B 1
10 Blower Back 25089B 1
11 Blower Motor 80442 1
12 Blower Cover 25090B 1
13 Ash Pan 69408B 1
14 Fire Brick (4½ x 9) 89066 17
15 Fire Brick (6 x 8¼) 891095 2
16 Half Brick (2¼ x 9) 23887 4
17 Half Brick (4½ x 4½) 24103 1
18 Ash Plug 40487 1
19 Leg 25268 4
16 17
18
19
