USSC Cavalier A9740L - Parts List for Heater Assembly

To Next Page

To Previous Page

PARTS LIST FOR HEATER ASSEMBLY

KEY PART # DESCRIPTION QTY.

1 69113 CABINET TOP WELDMENT 1

2 69134 FIREBOX BACK WELDMENT 1

3 69065 FIREBOX TOP WELDMENT 1

4 69102 INSIDE BACK WELDMENT 1

5 69070 FIREBOX WELDMENT 1

6 24469 FIREBOX BOTTOM 1

7 69084 PEDESTAL WELDMENT 1

8 24455 PEDESTAL BASE 1

9 24457 CONTROL DOOR 1

10 89899 BRASS KNOB 1

11 83323 8-32 x 3/8 PH MACHINE SCREW 1

12 24536 FRONT SCREEN (PAINTED) 1

13 89825 BRASS TRIM 2

N/S 89824 MAGNETIC LATCH 1

N/S 83172 #10A x 1/2 HX W SM SCREWS 58

IMPORTANT NOTICE: WHEN ORDERING CABINET PARTS, PLACE THE APPROPRIATE

CODE AFTER THE PART NUMBER THAT CORRESPONDS TO THE COLOR OF YOUR UNIT.

ALMOND = A

CHARCOAL GRAY = C

GREEN = G

N/S = NOT SHOWN
