18
PARTS LIST FOR GAS LOG ASSEMBLY
KEY PART # DESCRIPTION QTY.
1 24610 BURNER PLATE 1
2 24611 CONTROL BRACKET 1
3 81189 CONTROL VALVE (NATURAL) 1
81190 CONTROL VALVE (L.P.) 1
4 83251 10-24 x 1 SL ROD 2
5 83244 10-24 KEP NUT 2
N/S 83343 #10 X 1/2 HX HD SCREW 8
6 89831 BURNER/CONTROL FITTING 1
7 89834 1/4" TUBE, BURNER/REGULATOR 1
8 89838 1/4 CC X 3/8-27 FITTING 1
9 89839 1/4 COMPRESSION NUT 1
10 89840 1/4 COMPRESSION SLEEVE 1
11 24612 PILOT BRACKET 1
12 89872 "O.P. AMERICA" NAT. PILOT 1
89873 "O.P. AMERICA" L.P. PILOT 1
N/S 83437 #8-1/2 HX HD SCREW (TO MOUNT PILOT) 2
13 89841 3/16 COMPRESSION NUT 1
14 89842 3/16 COMPRESSION SLEEVE 1
15 89829 #47 NATURAL BURNER ORIFICE(FRONT) 1
89836 #55 L.P. BURNER ORIFICE (FRONT) 1
16 89830 #48 NATURAL BURNER ORIFICE(REAR) 1
89836 #55 L.P. BURNER ORIFICE (REAR) 1
17 24613 BURNER (PAINTED) 2
18 89826 LOG SET (CONSISTS OF 4 PIECES) 1
a 89826-1 FRONT LOG -
b 89826-2 REAR LOG -
c 89826-3 RIGHT TWIG -
d 89826-4 LEFT TWIG -
19 89856 3/16" LOXIT FITTING 1
N/S 86318 16GA WIRE LINK 1FT.
20 89855 PILOT TUBE 1
N/S = NOT SHOWN
