Page #6 background image
Specifications
Operating voltage range
15.20 to 19.95 VDC
Current
Standby
Activated
310 µA
135 µA
Maximum line impedance
Refer to the control panel installation
manual
Ground fault impedance
10 kΩ
Output ratings (special
applications)
24 VDC
25 VRMS audio
70 VRMS audio
EOL resistor value
Circuit resistance
Circuit capacitance
2 A
50 W
35 W
47 kΩ
Refer to the control panel installation
manual
0.1 µF max.
EOLR
47 kΩ (P/N EOL-47)
Circuit designation
Signaling line circuits
Telephone riser circuits
Notification line circuits
Class A, Style 6 or Class B, Style 4
Class B, Style 4
Class B, Style Y
LPCB/CP
R electrical box
Requirements
Minimum size W × H × D
Plastic box with cover plate, no gaps
or unused holes
3.5 × 3.5 × 1.5 in. (85 × 85 × 38 mm)
Compatible electrical boxes
2-1/2 in. (64 mm) deep dual-gang box;
4 in. square box 1-1/2 in. (38 mm)
deep box with a dual-gang cover
Wire sizes
12 to 18 AWG (1.0 to 4.0 mm²)
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
0 to 93%, noncondensing
Storage temperature range
4 to 140°F (−20 to 60°C)
Regulatory information
Manufacturer
Edwards, A Division of UTC Fire & Security
Americas Corporation, Inc.
8985 Town Center Parkway, Bradenton, FL
34202, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat
7, 6003 DH Weert, Netherlands
Year of manufacture
The first two digits of the DATE MFG number
(located on the product identification label) are
the year of manufacture.
FCC compliance
This device complies with part 15 of the FCC
Rules. Operation is
subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
North American
standards
CAN/ULC-S527, UL 864
EN 54
EN 54-18: 2005 Input/output devices
EU
compliance
CP
R certificates 0832-CPR-F0840
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information, see:
www.recyclethis.info.
Contact information
For contact information, see www.est-fire.com.
6 / 6 P/N 387022P-EN • REV 12 • ISS 22JUN15

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the UTC Fire and Security EST SIGA-CC1 and is the answer not in the manual?

UTC Fire and Security EST SIGA-CC1 Specifications

Power IconPower
operating voltage range15.20 to 19.95 VDC
standby current310 µA
activated current135 µA
Output Ratings IconOutput Ratings
output voltage for special applications24 VDC
output current for special applications2 A
audio output 25 VRMS50 W
audio output 70 VRMS35 W
Line and Circuit Specifications IconLine and Circuit Specifications
maximum line impedanceRefer to the control panel installation manual
ground fault impedance10 kΩ
EOL resistor value47 kΩ
Dimensions and Sizes IconDimensions and Sizes
minimum box size3.5 × 3.5 × 1.5 in. (85 × 85 × 38 mm)
compatible electrical box depth2-1/2 in. (64 mm)
wire sizes12 to 18 AWG (1.0 to 4.0 mm²)
Operating Environment IconOperating Environment
operating temperature range32 to 120°F (0 to 49°C)
relative humidity0 to 93%, noncondensing
storage temperature range−4 to 140°F (−20 to 60°C)
