V-Show B198 - DMX512 Channel Functions

12
system message
Option
Description
Reset error
message
If the red ERR indicator is on, it means that the lamp is running
wrong, and you can enter the sub-interface to view the details.
DMX data
monitoring
This enters the sub-interface to display the channel value
numerically for viewing
Sensor information
Real-time monitoring of the status of various photoelectric
switches and Hall sensors on the lamp
Hardware version
number
Lamp hardware information
Software version
number
Lighting software version
Total usage time
Cumulative use time (accurate to the minute)
11.DMX512Channel
NO.
Channel
function
Value
Description
1
X
0-255
0--540°
2
X fine-tuning
0-255
X axis 16bit
3
Y
0-255
0--270°
4
Y fine-tuning
0-255
Y axis 16bit
5
XY speed
regulation
0-255
speed
6
Dimming
0-255
0%-100% dimming
7
Strobe
0-3
Lights off
4-99
Synchronous strobe
100-149
Pulse strobe
150-199
Strobe
200-250
Random strobe
251-255
Light up
8
colour
0-1
White
2-7
Color 1
8-13
Color 2
14-19
Color 3
20-25
Color 4
26-31
Color 5
32-37
Color 6
38-43
Color 7
44-49
Color 8
50-55
Color 9
