V-Sol V2801RGW User Manual

GPON 1GE+WiFi ONU Introduction_V1.1
2 Access the world
1.3 Application Chart
Figure 2 Application Chart
1.3 Technical parameters
Technical item
1GE+WiFi
PON interface
1 GPON port(GPON Class B+)
Wavelength:Tx1310nm,Rx 1490nm
SC/UPC connector
Receiving sensitivity: ≤-28dBm
Transmitting optical power: 0~+4dBm
Transmission distance: 20KM
LAN interface
1 x 10/100/1000Mbps auto adaptive Ethernet interfaces.10/100/1000M
Full/Half, RJ45 connector
WiFi interface
Compliant with IEEE802.11b/g/n
Operating frequency: 2.412-2.462GHz
support MIMO, rate up to 300Mbps
2T2R,2 external antenna 5dBi
Support: multiple SSID
Channel:13
LED
5, For Status of POWER、LOS、PON、LAN、WiFi
Operating
condition
Temperature: 0℃～+50℃
Humidity: 10%～90%（non-condensing）
Storing
condition
Temperature : -30℃～+60℃
Humidity :10%～90%（non-condensing）
Power supply
DC 12V/0.5A
Power
consumption
≤6W
EPON/GPON OLT
