V-Sol V2801RGW User Manual

GPON 1GE+WiFi ONU Introduction_V1.1
3 Access the world
Dimension
120mm×7 8mm×30mm（L×W×H）
Net weight
0.15Kg
Table 2 Technical parameters
1.4 Panel lights
LED
Mark
Status
Description
Power
POWER
On
The device is powered up.
Off
The device is powered down.
Optical signal
loss
LOS
Blink
Device does not receive optical signals.
Off
Device has received optical signal.
Registration
REG
On
The device is registered to the PON system.
Off
Device is not registered to the PON system.
Blink
Device registration is incorrect.
Interface
LINK/ACT
On
Port is connected properly (LINK).
Off
Port connection exception or not connected.
Blink
Port is sending or/and receiving data (ACT).
WiFi
WiFi
On
WiFi running.
Off
WiFi not working.
Table 3 Panel lights on
1.6 Interface description
Port Type
Function
PON
Connect PON port with internet by SC/UPC type, single mode optical
fiber cable.
LAN
Connect device with ethernet port by RJ-45 cat5 cable.
RST
Press down reset button and keep1-5seconds to make the device
restart and recover from the factory default settings.
Power ON/OFF
Power on and Power off.
DC12V
Connect with power adapter.
Table 4 Interface description

V-Sol V2801RGW Specifications

General

Brand	V-Sol
Model	V2801RGW
Category	Modem
Language	English
