V7 DOCKTB4PT - Lato Posteriore

PANORAMICA
1. RJ45 x1
• Ampiezza di banda di 10M/100M/1000M/2.5G
• Conforme agli standard IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz. supporto IEEE
802.3az-2010 (EEE), IEEE 802.1P, IEEE 802.1Q, IEEE 802.3x
• Supporta Wake-On-LAN e Wake-On-WAN
• Spia LED: 1) Luce assente: spento. 2) Arancione: acceso. 3) Blu: Connessione host OK.
LATO POSTERIORE
1
2
3
4
Un monitor DisplayPort:
· 8K/30Hz max
· 4K UHD 60/120/144Hz
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
HDMI:
· 4K UHD 30/60Hz max
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
Due monitor HDMI/DisplayPort:
· 4K UHD 30/60Hz max
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
Tre monitor HDMI/DisplayPort:
· 4K UHD 30/60Hz max
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
HDMI/DisplayPort n. 2:
· 4K UHD 30Hz max
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
2.
