OVERVIEW
1. RJ45 x1
• 10M/100M/1000M/2.5G bandwidth
• Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz. support IEEE 802.3az-
2010(EEE), IEEE 802.1P, IEEE 802.1Q, IEEE 802.3x
• Supports Wake-On-LAN and Wake-On-WAN
• LED indicator: 1) No light: power o. 2) Orange: power on. 3) Blue: Host connection OK.
BACK
1
2
3
4
One Display DisplayPort:
·Max 8K/30Hz
·4K UHD 60/120/144Hz
·2K WQHD 60/120/144/240Hz
·1080P 60/120/144/240Hz
HDMI:
·Max 4K UHD 30/60Hz
·2K WQHD 60/120/144/240Hz
·1080P 60/120/144/240Hz
Two Displays HDMI / DisplayPort:
·Max 4K UHD 30/60Hz
·2K WQHD 60/120/144/240Hz
·1080P 60/120/144/240Hz
Three Displays HDMI / DisplayPort:
·Max 4K UHD 30/60Hz
·2K WQHD 60/120/144/240Hz
·1080P 60/120/144/240Hz
HDMI / DisplayPort #2:
·Max 4K UHD 30Hz
·2K WQHD 60/120/144/240Hz
·1080P 60/120/144/240Hz
2.
