Board Identification
Not actual size
TOP
Qty:1
A
RIGHT SIDE PANEL
Qty:1
C
LEFT SIDE PANEL
Qty:1
3-34
B
PARTITION
Qty:1
D
BACK SLAT
Qty:1
F
FRONT SLAT
Qty:1
E
REAR LOWER PANEL
Qty:1
G
UPPER RIGHT PANEL
Qty:1
I
UPPER LEFT PANEL
Qty:1
H
