Parts Information
HOUSING
Part # Part Name Qty
1 Chassis components 1
2 976169
Washer, insulated outside on brass
mounting post
2
3 Copper lug 2
4 I Type Non-Metallic 5
5 976154 Arm, Top Bar 4
6 976234 Rubber washer 4
7 976233 Arm Spring 4
8 976231 Magnetic Plate 1
9 978143 Nylock Lock Nut 3/8 2
10 976142 Power switch 1
11 979951 Clear side panel 1
12 976144 Handle 2
13 Rubber gasket 4
14 976158 Rod, Arm 2
15 976163 Spacer 3
16 976216 Arm 2
Part # Part Name Qty
17 Pivot 1
18 976159 Washer 2
19 976161 Top Cover 1
20 979952 Sticker 1
21 976153 Silicone cover 2
22 Silicone cover press plate 2
23 976154 Top Bar, Arm 1
24 979417 Seal Pad 1
25 978171 Screw 2
26 976252 On/O Decal 1
27 Data plate 1
28 976167 Main switch 1
29 976168 Brass post 2
30 976169
Upper insulating washer, outside
mounting post
2
31 976171 Seal Bar Post 3
BS116 Impulse Bag Sealer | User Guide
ARY, Inc. | 11880 College Blvd Suite 550 Overland Park, KS 66210 | www.VacMasterFresh.com | 800-821-7849
8
