VP230 Chamber Vacuum Sealer | User Guide
63
Socket Plug Bracket
1
pc
64
Socket Fuse (10 amp)
1
pc
979462
65
Socket Plug Screw (M3x8)
2
pc
66
Socket Plug
1
pc
979463
67
Exhaust Filter Hose Barb
1
pc
979143
68
Air Intake Filter
1
pc
979144
69
Air Intake Filter Bracket
1
pc
979145
70
Air Intake Filter Hose Barb
1
pc
979146
71
Air Intake Filter Bracket Screw (M5x12)
3
pc
72
Support Arm
1
pc
73
Seal Transformer
1
pc
979464
74
Power Module
1
pc
979465
75
Power Module Screw (M3x10)
4
pc
76
Control Relay Screw (M3x6)
4
pc
77
Control Relay
2
pc
979466
78 Seal Transformer Screw (M4x12)
4
pc
79
Support Arm Spring
1
pc
979148
80
Support Arm Nut (M5)
1
pc
81
Support Arm Bracket
1
pc
82
Solenoid Valve Hose
1.5
m
979156
83
Support Arm Screw (M5x16)
1
pc
84
Bottom Housing Plate
1
pc
85
Timer Relay
1
pc
979467
86
Timer Relay Mount Block
4
pc
87
Power Switch
1
pc
979468
88
Power Switch Mount
1
pc
89
Vacmaster Decal Panel
1
pc
979130
90
Main Board
1
pc
979469
91
Vacuum Gauge
1
pc
979126
92
Control Panel Mount
1
pc
979470
93
Control Panel Screw (M3x8)
4
pc
94
Control Panel Decal
1
pc
979122
95
VP230 Decal
1
pc
979472
96
Vacmaster Decal Panel Screw (M3x8)
4
pc
97
Lid Latch Nut (M6)
2
pc
98
Lid Latch
1
pc
979170
99
Lid Latch Screw (M6x20)
1
pc
Parts Information
