Fig. 2
Name Quantity
Part
Number
Assembly
Part Number
1 Instrument Panel 1 979125
2 Vacuum Gauge 1
979126
3 Circuit Board 1
979127
4 Cover Plate 1
5 Cable Sheath 1
6 Housing Case 1
7 Lid Latch Assembly 1
979170
8 Power Switch Bracket 1
979137
9 Power Switch 1
979138
10 Rear Cover 1
11 Decal, Instrument Panel 1 979124
11
