Operation handle
1. Operating handle in outer position
• The lift is raised to its highest position with
load.
• Without load, the lift is raised to its pre-set
balancing position.
2. Operating handle in partly depressed position
• The load is raised or lowered, depending
on the amount the control is depressed.
3. Operating handle in completely depressed
position.
• With load, the lift is lowered quickly and the
load is released when it has reached a solid
support.
• Without load, the lift is lowered quickly
Gripping the load from above
•
Completely depress the operating handle, put
the suction cup on the load to be lifted. Release
the handle fully or partly to lift the load.
Gripping the load from the side
• Angle the suction cup forwards when the load
is to be lifted from the side
Do not lift on surfaces which contain loose
objects. These objects could be sucked into the
suction cup and make the load fall off!
Only lift loads which are so strong that there
is no risk they could fall apart when lifted.
! Use the facility of lifting from the side when
the top does not have a suitable, grippable
surface.
...OPERATION...
USAGE
GRIPPING THE LOAD
"
"
