VADANIA VD2053 - Product Specifications; Product Name and Model; Material Composition; Installation Method

Page 2
NAME：VADANIA HEAVY DUTY DRAWER SLIDES VD2053
MATERIAL: COLD-ROLLED （COLD ROLLED） STEEL
INSTALLATION METHOD: SIDE MOUNT
MAXIMUM LOAD CAPACITY: 256LB / 120KG.
MINI DEPTH OF CABINET: DRAWER LENGTH + 0.12IN / 3MM
SLIDE STYLE: 3 FOLDS FULL EXTENSION, SIDE MOUNT, SEPARA-
BLE, WITH LOCK
PLATE THICKNESS: OUTER SLIDER 0.08IN(2MM) / MIDDLE SLIDER
0.08IN(2MM) / INNER SLIDER 0.08IN(2MM)
SIZE: 12-40IN / 300-1000MM
SCOPE OF APPLICATION: MECHANICAL CABINETS, WAREHOUSE
CABINETS, INDUSTRIAL CABINETS, FINANCIAL EQUIPMENT, TRUCK
DRAWERS
Unit: mm
Inner Slider Outer Slider
