Fan settings
• Fan settings are based on product lift versus a pre-defined chart.
• Product lift should be 18-24”
• To test product lift:
• Remove secondary hose from furthest opener to outside on either end of drill. This would involve
either removing the hose from metal drop tube, or sliding complete rubber drop tube from support.
• Attach secondary hose to frame pointing upward.
• Operate drill at normal seeding speed and observe product lift.
• Adjust fan RPM until 18-24” of product lift is achieved.
• Re-install secondary hose on machine.
• Verify field operation by operating and check for product on ground and proper depth being achieved.
• High and Low limit fan alarms are setting in the settings menu, Configure Fans tab.
Fan Displays Fan Alarm Limit Settings
