Appendix
0020241666_01 Safety instructions
13
VIH RW 300/3
BR
VIH RW 400/3
BR
VIH RW 500/3
BR
VIH RW 300/3
MR
VIH RW 400/3
MR
VIH RW 500/3
MR
Continuous domestic hot
water output (heating circuit)
(60°C35K)
1,063 l/h 1,531 l/h 2,041 l/h 1,063 l/h 1,531 l/h 2,041 l/h
Domestic hot water output
(50 °C)
302 l/10 min 403 l/10 min 494 l/10 min 302 l/10 min 403 l/10 min 494 l/10 min
Domestic hot water output
(55 °C)
340 l/10 min 453 l/10 min 494 l/10 min 340 l/10 min 453 l/10 min 494 l/10 min
Domestic hot water output
(60 °C)
377 l/10 min 504 l/10 min 618 l/10 min 377 l/10 min 504 l/10 min 618 l/10 min
Domestic hot water output
(65 °C)
415 l/10 min 554 l/10 min 679 l/10 min 415 l/10 min 554 l/10 min 679 l/10 min
Domestic hot water output
(70 °C)
453 l/10 min 604 l/10 min 741 l/10 min 453 l/10 min 604 l/10 min 741 l/10 min
Specific flow rate Delta
(50°C30K)
35.2 l/min 47.0 l/min 57.7 l/min 35.2 l/min 47.0 l/min 57.7 l/min
Specific flow rate Delta
(55°C30K)
39.6 l/min 52.9 l/min 64.9 l/min 39.6 l/min 52.9 l/min 64.9 l/min
Specific flow rate Delta
(60°C30K)
44.0 l/min 58.8 l/min 72.1 l/min 44.0 l/min 58.8 l/min 72.1 l/min
Specific flow rate Delta
(65°C30K)
48.4 l/min 64.6 l/min 79.3 l/min 48.4 l/min 64.6 l/min 79.3 l/min
Specific flow rate Delta
(70°C30K)
52.8 l/min 70.5 l/min 86.5 l/min 52.8 l/min 70.5 l/min 86.5 l/min
Nominal heating medium
volume flow for the heating
circuit
1.72 m³/h 2.58 m³/h 3.44 m³/h 1.72 m ³/h 2.58 m³/h 3.44 m³/h
Technical data – VIH S output
VIH S 300/3
BR
VIH S 400/3
BR
VIH S 500/3
BR
VIH S 300/3
MR
VIH S 400/3
MR
VIH S 500/3
MR
Output characteristic figure
NL (50 °C)
1.0 1.9 1.9 1.0 1.9 1.9
Output characteristic figure
NL (55 °C)
1.1 2.2 2.2 1.1 2.2 2.2
Output characteristic figure
NL (60 °C)
1.3 2.6 2.6 1.3 2.6 2.6
Output characteristic figure
NL (65 °C)
1.4 3.0 3.1 1.4 3.0 3.1
Output characteristic figure
NL (70 °C)
1.6 3.7 3.7 1.6 3.7 3.7
Continuous domestic hot
water output (heating circuit)
(60°C35K)
13.5 kW 16.4 kW 16.4 kW 13.5 kW 16.4 kW 16.4 kW
Continuous domestic hot
water output (heating circuit)
(70°C35K)
18.3 kW 22.3 kW 22.3 kW 18.3 kW 22.3 kW 22.3 kW
Continuous domestic hot
water output (heating circuit)
(80°C35K)
22.8 kW 27.9 kW 27.9 kW 22.8 kW 27.9 kW 27.9 kW
Continuous domestic hot
water output (heating circuit)
(60°C35K)
331 l/h 404 l/h 404 l/h 331 l/h 404 l/h 404 l/h
Continuous domestic hot
water output (heating circuit)
(70°C35K)
448 l/h 549 l/h 549 l/h 448 l/h 549 l/h 549 l/h
Continuous domestic hot
water output (heating circuit)
(80°C35K)
562 l/h 686 l/h 686 l/h 562 l/h 686 l/h 686 l/h
Domestic hot water output
(50 °C)
144 l/10 min 191 l/10 min 191 l/10 min 144 l/10 min 191 l/10 min 191 l/10 min
Domestic hot water output
(55 °C)
150 l/10 min 203 l/10 min 207 l/10 min 150 l/10 min 203 l/10 min 207 l/10 min
