Val Controls I 24-BF Series User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
48/58
Description: Options for controlling access of host
computers and local control panes to operating
tuning and alarm parameters of the block.
IO_OPTS
[Options]
Length 2 byte
Read Write
Value 0x0000
Description:
Option which the user can select to alter Input and
Output block processing
Only the Low cutoff can be enabled/disabled
STATUS_OPTS
[Options]
Length 2 byte
Read Write
Value 0x0000
Description: Option which the user can select block
processing of status.
CHANNEL
[Process]
Length 2 byte
Read Write
Description: The CHANNEL 1 to 8
FIELD_VAL
[Process]
[Trends]
1: Value
Length 4 byte
Read Only
Value: 0
2: Status
Length 1 byte
Read Only
Description: Raw value of the field device in % of
PV range.
UPDATE_EVT
[Others]
1 Unacknowledged:
Length: 1 bytes
Read Write
2 Update State:
Length: 1 bytes
Read Only
3 Time Stamp:
Length: 8 bytes
Read Only
4 Static Revision:
Length: 2 bytes
