the static data.
BLOCK_ALM
[Others]
1: Unacknowledged
Length: 1 bytes
Read Write
2: Alarm State
Length: 1 bytes
Read Only
3: Time Stamp
Length: 8 bytes
Read Only
4: Sub code
Length: 2 bytes
Read Only
5: Value
Length: 1 bytes
Read Only
Description: The block alarm is used for all
configuration hardware connected failure or system
problems in the block. The cause of the alert is
entered in the sub code field.
ALARM_SUM
[Others]
Description: The current alert status unacknowledged
states, unreported states, and disabled states of the
alarms associated with the function block.
DISC_ALM
[Others]
Description: The status and time stamp associated
with the discrete alarm
6.6 Appendix - Discrete Output Function Block (DO)
Digital Output Function (DO) Block
Label / Name /
Handling
Idx
rel.
Description / Format
ST_REV
[Others]
Length 2 byte
Read Only
Description: The revision level of the Static data
associated with the Function Block. The revision
level is incremented each time a static parameter
value in the block is changed.
TAG_DESC
[Process]
Length 32 byte
