changes to FSTATE_VAL value.
STATUS_OPTS
[Options]
Description: Options which the user may select in the
block processing of status.
ALERT_KEY
[Alarms]
Description: The identification number of the plant
unit. This information may be used in the host for
sorting alarms etc.
ACK_OPTION
[Alarms]
Description: Selection of whether alarms associated
with the function block will be automatically
acknowledged.
DISC_PRI
[Alarms]
Description: Priority of the Discrete alarm
DISC_LIM
[Alarms]
Description: The state of the discrete input that
causes an alarm.
Any number from 0 to 255 may be. State 255
specifies
that no alarm indication is to be shown
BLOCK_ERR
[Diagnostic]
Description: The summary of active error conditions
associated
with the block. The supported block errors in the
Discrete Input function block are Simulate active,
Input
failure/process variable has Bad status, and Out of
service.
STRATEGY
[Others]
Description: The strategy field can be used to
identify grouping of blocks. This data is not checked
or processed by the block.
UPDATE_EVT
[Others]
1 Unacknowledged:
Length: 1 bytes
Read Write
2 Update State:
Length: 1 bytes
Read Only
3 Time Stamp:
Length: 8 bytes
Read Only
4 Static Revision:
Length: 2 bytes
Read Only
Relative Index:
Length: 2 bytes
Read Only
Description: This alert is generated by any change to
