1*28182 1 Air Valve Poppet (For all except
PA6-TAL & PA6-HUNT)
2*251717 1 O-ring (1" x 5/8 x 3/16; For all except
PA6E, PA6V, PA6-2E, PA6-HUNT &
PA6-2V)
251718 1 O-ring (1" x 5/8 x 3/16; For PA6-2V &
PA6V)
251719 1 O-ring (1" x 5/8 x 3/16; For PA6-2E &
PA6E)
3 28387 1 Muffler (For all except PA6-HUNT)
4*28239 1 Gasket
5 52390 1 Piston Body
6*14265 2 Piston Ring (For all except
PA6-HYDRA & PA6-SEAL)
*252347 2 Piston Ring (For PA6-HYDRA &
PA6-SEAL)
7*251835 2 O-ring
(2-5/16 x 2-1/8 x 3/32; For all
except PA6E, PA6V, PA6-2E, PA6-2V,
PA6-HYDRA & PA6-SEAL)
251865 2 O-ring (2-5/16 x 2-1/8 x 3/32;
For PA6-2V & PA6V)
251866 2 O-ring (2-5/16 x 2-1/8 x 3/32;
For PA6-2E & PA6E)
252348 2 O-ring (
2-5/16 x 2-1/8 x 3/32;
For PA6-HYDRA & PA6-SEAL)
8*10276 1 O-ring (1" X 3/4 X 1/8; For all except
PA6E, PA6V, PA6-2E & PA6-2V)
19026 1 O-ring (1" X 3/4 X 1/8; For PA6V &
PA6-2V)
250188 1 O-ring (1" X 3/4 X 1/8; For PA6E &
PA6-2E)
9*10272 1 O-ring (3/4 X 9/16 X 3/32; For all
except PA6M, PA6M-DE-STA-CO,
PA6-2E, PA6-2V, PA6V, PA6M-CAR,
PA6E & PA6M-DK)
*10272 2 O-ring (3/4 X 9/16 X 3/32; For PA6M,
PA6M-CAR, PA6M-ROM, PA6M-DE-
STA-CO & PA6M-DK)
18998 1 O-ring (3/4 X 9/16 X 3/32; For PA6-2V
& PA6V)
250194 1 O-ring (3/4 X 9/16 X 3/32; For PA6-2E
& PA6E)
10 34378 1 Check Valve Body
11 *250638 1 Filter Disc (For all except PA6-
HYDRA, PA6-HUNT, PA6-BEST
&
PA6-SEAL
)
12 *11088 2 Retaining Ring (9/16 hole; For all
except PA6-HYDRA, PA6-HUNT,
PA6-BEST
& PA6-SEAL
)
13 *12522 2 O-ring
(3/8 X 1/4 X 1/16; Urethane;
For all
except
PA6E, PA6V, PA6-2E, & PA6-2V)
11438 2 O-ring (3/8 X 1/4 X 1/16; For PA6V &
PA6-2V)
17715 2 O-ring (3/8 X 1/4 X 1/16; For PA6E &
PA6-2E)
211053 2 O-ring (.37 x .25; For PA6M-1-STEL)
14 *11841 1 O-ring
(1-5/8 x 1-3/8 x 1/8; For all
except PA6E, PA6V, PA6-2E & PA6-2V)
19035 1 O-ring
(1-5/8 x 1-3/8 x 1/8; For PA6V &
PA6-2V)
251695 1 O-ring
(1-5/8 x 1-3/8 x 1/8; For PA6E &
PA6-2E)
15 *351021 1 Gasket
16 *10442 1 Washer (3/8 X 1/4 X 1/32)
17 10002 1 Cap Screw (1/4-20 UNC X 3/8 Lg.;
Torque to 90/110 in. lbs.)
18 *10445 1 Compression Spring
(5/32 O.D. X 3/4 Lg.)
19 *10423 1 Steel Ball (9/32 Dia.; For all except
PA6M-2, PA6-2, PA6-2E, PA6-2N,
PA6-2V & PA6-2-FS-LR)
*10423 2 Steel Ball (9/32 Dia.; For PA6M-2,
PA6-2, PA6-2E, PA6-2N, PA6-2V &
PA6-2-FS-LR)
20 -------- - Relief Valve (When ordering a
replacement relief valve refer to
stamped number on the outside of
the relief valve. See note below.
Apply loctite 592 [Power Team
#905516] or equiv. & torque to
150/170 in. lbs.)
21 45278 1 Piston Cylinder (Torque to
90/100 ft. lbs. oiled.)
22 *10375 1 Steel Ball (1/4 Dia.; For all except
PA6-2E, PA6-2N, PA6-2V, PA6-2,
PA6-2-FS-LR & PA6M-2)
23 *10261 1 Copper Washer
(3/4 X 19/32 X 1/32)
24 308893 1 Filter Adapter (Torque to 40/50 ft.
lbs. oiled.; For all except PA6-2E,
PA6-2N, PA6-2V, PA6-HYDRA,
PA6-2, PA6M-2, PA6-2-FS-LR,
PA6-HUNT
& PA6-SEAL; See back
sheet 5 of 6 for pumps with 2 gal.
reservoirs.
)
308366 1 Filter Adapter (Torque to 40/50 ft.
lbs. oiled.; For PA6-HUNT)
350553 1 Filter Adapter Torque to 40/50 ft. lbs.
oiled, For PA6-SEAL)
25 214578 1 Filter (For all reservoir sizes except 2
gal. reservoirs built after June 1, 1998;
For all except PA6-SEAL)
29682 1 Filter (For PA6-SEAL)
26 214586 1 Retaining Ring (Internal; For all
reservoir sizes except 2 gal. reservoirs
built after June 1, 1998; PA6-HYDRA
& PA6-SEAL
)
27 *10263 1 Copper Washer (1" X .765 X 1/32)
28 *13934 1 U-cup & Backup
29 *304295 1 Retainer (Note: See "INSTRUCTIONS
FOR RETAINER REPLACEMENT"
on back sheet 6 of 6)
30 *17429 2 Backup Washer
(2-15/16 X 2-3/4 X .045)
31 *13938 1 Compression Spring
(1.452 O.D. X 4-7/16 Lg.)
32 28226 1 Piston
33 203143 1 Bumper
34 210994 1 Spring Guide
35 37434 1 Air Cylinder (Note: Locate groove on
upper half (top) of pump with
chamfered tube end towards rear
head as shown.)
Item Part No. Item Part No.
No. No. Req'd Description No. No. Req'd Description
Continued-
NOTE:
Standard relief valves are set at 10,100/10,700 PSI.
Relief valves pre-set at special settings are available.
Refer to your pump model number or contact Power Team Technical Services.
Parts List, Form No. 101652, Back sheet 4 of 6
Part numbers marked with an asterisk (*) are contained in a Repair Kit see
sheet 6 of 6 for individual repair kit information.
Note: Shaded areas reflect last
revision(s) made to this form.
