Using the appliance
B
Installing the dishwasher under a worktop
If you wish to place your appliance under a worktop, there must be sufficient space to do so
and the pipework must be suitable for this purpose (1).
If the space under the worktop is suitable for mounting your appliance, remove the dishwasher
top as shown in the illustration (2).
1
2
3
4
Min 570
H
H1: min A
H2: min B1
H3: min B2
598
570
Min 820
Min 600
A B
All
products
B1 B2
Height
of the
product
(± 2 mm)
820 mm
830
mm
835
mm
A: If there is no felt on top of the product, you must take into account the height of the product.
B1: If there is felt on top of the product with the 2nd rack, you must take into account the
height of the product.
B2: If there is felt on top of the product with the 3rd rack, you must take into account the
height of the product.
WARNING
The work surface under which the appliance is to be
placed must be stable to avoid loss of balance.
